GA733上下复合送料极厚料缝纫机


特点:

本机型是上篷极厚料缝纫机系列的又一新品,特殊设计的机身刚性强,宽大的操作台可以轻松地缝制大型物件,大惯量的主轴上轮,能产生巨大的穿刺力,送布牙、压脚‘协和的同步送料方式,特别适用于厚的及多层物料的车缝,即使滑溜或胶粘的物料,亦可缝纫自如,得心应手。本机采用凸轮挑线,大型半回转摆梭钩线,使更换底线次数减少。是缝制安全带、马具、皮箱、抛光轮、帐篷、风帆、车盖、装订书册的理想设备。
Characteristics:
This machine is another new product of Shangpeng sewing machine for extremely think materials .Specialiy designed machine boby has strong rigidity and spacious operation table is able to sew large-scale objects easily.Drivers with large inertia presser is especially suitabie for thick and multilayer materials,Even though the material is easy to be slipping and sticky,it is also easy to sew the material by this kind of sewing machine with high proficiencu.This machine adopts cam to take-up thread and large semi-rotating shuttle to hook thread with less change of bottom thread,it is an ideal device for sewing safety beit,horse gear,leather suitcase,buff wheel,tent,sails,bonnet and bookbinding.
主要技术参数Main Parameters:

型号Mode GA733
   线迹长度Stitch length
   0-13mm
   缝速高达 Max.Sewing speed
   700针/分 needles/min
   压脚提升 Presser food lift
 手提 By hand
   25毫米 mm
 气动 By knee    32—38毫米 mm
   针杆行程 Needle bar stroke
   75毫米 mm
   机针 Needle size
   SM×1000 28#
   摆梭 Oscillating shuttle
   特大型半回转摆梭KSP7-31
   压脚交替上升量 Aiternating lifting distance of presser
   5~7毫米(标准6毫米) 5~7mm(Standard 6mm)
   润滑方式 Lubrication
   手动润滑 Manual
   作业空间 Operating room
   420×250毫米 mm
   电机 Motor
   550瓦缝纫机专用电机1400转/分
550W Clutch motor 1400r.p.m
   机头重量 Machine head weight
   105kg kg
